InfiRay Xview-V2-90 thermal camera
InfiRay Xview-V2-90 thermal camera
735 €

InfiRay Xview-V2-90 thermal camera

Item number:
IRAXviewV290
InfiRay Xview-V2-90 thermal camera
InfiRay Xview-V2-90 thermal camera
InfiRay Xview-V2-90 thermal camera
InfiRay Xview-V2-90 thermal camera
InfiRay Xview-V2-90 thermal camera
InfiRay Xview-V2-90 thermal camera
InfiRay Xview-V2-90 thermal camera
Available to order
Horizontal field of view (°)
Horizontal field of view (°) :
25.5
Screen
Screen:
3'' touchscreen
Lens
Lens:
9 mm fix focus
Thermal sensor
Thermal sensor:
256x192 12μm
Thermal sensor NETD
Thermal sensor NETD:
50 mK
User's Guide
User's Guide:

.

More details
735 €
Details

Thermometry Camera Xview Series

Xview is a pocket-size handheld thermal imaging camera which is embedded with 12μm strong thermal sensor, compactbut powerful-. Excellent thermal imagingperformance, easy operation for temperature measurement, Xview will bring high-level technical superiority into your colorful life.

Main specifications:

Resolution: 256 x 192

Pixel Size: 12μm

Focal length: 9.0mm

Application scenarios: Night patrols, plumbing/electrical/heating repairs, house leak checks, emergency rescue, animal research.

High resolution and frame rate offer clear and smooth imaging

  • 256 x 192 detector resolution provides ultimate clarity that you can classify your hair fromimages;
  • 25Hz frame rate guarantees smooth imaging output;
  • Various color palettes offer customized display options for different application scenes.

High-level Germanium lens for wide and versatile applications

  • Professional testing for instruments/meters/circuits, etc;
  • Security, night patrols, search and rescue(SAR)



Professional accurate temperature measurement

  • Connected with special APP, the Xview can offer point-line-planetemperature measurements;
  • NETD≤60mK with ±3℃ measuring accuracy;
  • -10℃～+80℃ wide measuring range;
  • Xview offers temperature correction parameters toensure more accurate measuring.
Data
Horizontal field of view (°) :
25.5
Screen:
3'' touchscreen
Lens:
9 mm fix focus
Thermal sensor:
256x192 12μm
Thermal sensor NETD:
50 mK
User's Guide:

.

Base magnification (x):
1
Color:
black
Data storage:
built-in memory, compatible up to 64 GB TF (micro SD)
Dimensions:
123x61x35 mm
Image repetition frequency:
25 Hz
In the box:
thermal camera, wrist strap, USB cable, user's manual
Other properties:
WiFi
Manufacturer:
InfiRay
Manufacturer's warranty:
3-year general warranty for the device, 10 years for the sensor, 2 years for the battery
Thermal camera type:
Handheld camera
Screen color modes:
8 colors
Field of view (°):
19.63°x14.71°
Measurement properties:

-20 - +120°,- up to +400°C-ig
Emission: 0,0 - 1,0
Magnification:
1x
Power supply:
built-in battery
Plugs:
USB-C
Sensor:
256x192 VOx microbolometer, NETD<=50 mK
Tripod thread:
-
Working / storage temperature:
-10 - +50°C / -30 - +70°C
Weight (g):
190
Video resolution:
256x192 .mp4
Water resistance:
IP54
